MOC3061 Triac Driver Optocoupler DIP-6
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | MOC3061 Optocouplers 6 pin Dip | 15 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 15 EGP
About this product
The MOC3061 is an optocoupler with a triac (bidirectional thyristor) output. It triggers the gate of an external triac in AC switching circuits while keeping the control side isolated. It is typically used with microcontrollers to switch AC loads such as lamps, fans and heaters through a separate triac.
Specifications
- Output type
- Triac (bidirectional thyristor) driver
- Isolation voltage (rms)
- 7500 V
- Peak repetitive off-state voltage (VDRM)
- 600 V
- Forward current
- 60 mA
- Static dv/dt
- 1500 V/µs
- Package
- DIP-6
Frequently asked questions
What is the price of MOC3061 Triac Driver Optocoupler DIP-6 in Egypt?
MOC3061 Triac Driver Optocoupler DIP-6 currently costs 15 EGP in Egypt.
Where can I buy MOC3061 Triac Driver Optocoupler DIP-6 in Egypt?
MOC3061 Triac Driver Optocoupler DIP-6 is available from Makers Electronics. Compare the offers above to find the best price.
Can it switch mains directly?
No. The MOC3061 only triggers the gate of an external triac, and the triac switches the load. Select the triac, gate resistor and snubber according to the datasheet.
Does the input LED need a resistor?
Yes. The input LED needs a series resistor sized for your supply voltage, keeping the forward current at or below 60 mA.
