MDP16-1-562 Bussed Resistor Network 5.6K Ohm 16-Pin DIP
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | MDP16-1-562 BUSSED RESISTOR NETWORKS 5.6KΩ DIP-16 | 75 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 75 EGP
About this product
MDP16-1-562 is a bussed resistor network containing 15 resistors of 5.6kΩ each, with ±2% tolerance and 0.125W per element, in a 16-pin DIP package. Its shared common pin lets one package serve as pull-up or pull-down resistors for multiple digital inputs. It helps reduce component count on compact microcontroller and logic boards.
Specifications
- Resistance per element
- 5.6kΩ
- Number of resistors
- 15 + common pin
- Package
- 16-pin DIP
- Tolerance
- ±2%
- Power per element
- 0.125W
Frequently asked questions
What is the price of MDP16-1-562 Bussed Resistor Network 5.6K Ohm 16-Pin DIP in Egypt?
MDP16-1-562 Bussed Resistor Network 5.6K Ohm 16-Pin DIP currently costs 75 EGP in Egypt.
Where can I buy MDP16-1-562 Bussed Resistor Network 5.6K Ohm 16-Pin DIP in Egypt?
MDP16-1-562 Bussed Resistor Network 5.6K Ohm 16-Pin DIP is available from Makers Electronics. Compare the offers above to find the best price.
How do I wire it for pull-down resistors?
Connect the common pin to ground and connect each of the other pins to a digital input. Each input is then pulled low through its own 5.6kΩ resistor. For pull-up use, connect the common pin to the positive supply instead.
Can I use it with a 3.3V microcontroller?
Yes, the resistor network itself is independent of the logic level. Use the common pin on the same rail as the logic supply you need the inputs pulled to, and confirm the pinout in the datasheet before wiring.
