MDP16-1-221 Bussed Resistor Network 220Ω DIP-16
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | MDP16-1-221 BUSSED RESISTOR NETWORKS 220Ω DIP-16 | 75 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 75 EGP
About this product
The MDP16-1-221 is a bussed resistor network with 15 resistors of 220Ω each sharing one common pin, housed in a 16-pin DIP package. Each element is rated at 0.125W with ±2% tolerance. It is used for pull-up and pull-down arrays on microcontroller inputs and logic lines, saving board space compared with discrete resistors.
Specifications
- Resistance
- 220Ω
- Resistors per network
- 15 + common pin
- Package
- DIP-16
- Power per element
- 0.125W
- Tolerance
- ±2%
- Configuration
- Bussed (common pin)
Frequently asked questions
What is the price of MDP16-1-221 Bussed Resistor Network 220Ω DIP-16 in Egypt?
MDP16-1-221 Bussed Resistor Network 220Ω DIP-16 currently costs 75 EGP in Egypt.
Where can I buy MDP16-1-221 Bussed Resistor Network 220Ω DIP-16 in Egypt?
MDP16-1-221 Bussed Resistor Network 220Ω DIP-16 is available from Makers Electronics. Compare the offers above to find the best price.
Can it be used with 5V logic?
Yes. Worst-case power per element is about 0.11W at 5V, within the 0.125W rating, and about 0.05W at 3.3V. Connect the common pin to VCC for pull-up or GND for pull-down.
Is the common pin always pin 1?
Not necessarily. Identify the common pin from the datasheet pinout for this exact part before connecting the network to your board.
