Murata BLM41PG600SN1L EMI Ferrite Bead 1806, 60Ω 6A
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 13 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
A 1806 surface-mount ferrite bead for filtering high-frequency noise on higher-current lines, with 60Ω impedance at 100 MHz and a 6A DC current rating. It is placed in series with a power or signal line to suppress EMI and RFI, for example on motor or regulator supply rails.
Specifications
- Impedance at 100 MHz
- 60 Ω
- DC current rating
- 6 A
- Package
- 1806 SMD
- Core material
- Ferrite
- Operating temperature
- -25 °C to +125 °C
- Number of pins
- 2
Frequently asked questions
Where should I place it in a circuit?
Place it in series with the noisy line, for example between a motor driver or regulator output and the sensitive circuit, with decoupling capacitors on the far side of the bead.
Is 6A enough for my load?
Keep the continuous DC current below the 6A rating. A bead loaded above its rating can overheat and saturate, which removes its filtering effect.
