BLM21PG300SN1D Murata SMD Ferrite Bead 30Ω 0805 4A
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | SMD Ferrite Beads 30Ω@100MHz ±25% 0805 | 0.75 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 0.75 EGP
About this product
BLM21PG300SN1D is a 0805 surface-mount ferrite bead with 30Ω impedance at 100 MHz, a 4A current rating and 14 mΩ DC resistance. It is used to suppress high-frequency noise on power rails and signal lines in digital and RF boards.
Specifications
- Impedance @ frequency
- 30Ω @ 100MHz
- Rated current
- 4A
- DC resistance
- 14mΩ
- Tolerance
- ±25%
- Circuits
- 1
- Package
- 0805
Frequently asked questions
What is the price of BLM21PG300SN1D Murata SMD Ferrite Bead 30Ω 0805 4A in Egypt?
BLM21PG300SN1D Murata SMD Ferrite Bead 30Ω 0805 4A currently costs 0.75 EGP in Egypt.
Where can I buy BLM21PG300SN1D Murata SMD Ferrite Bead 30Ω 0805 4A in Egypt?
BLM21PG300SN1D Murata SMD Ferrite Bead 30Ω 0805 4A is available from Makers Electronics. Compare the offers above to find the best price.
Where do I place a ferrite bead on a power rail?
Place it in series between the regulator output and the IC supply pin, and put decoupling capacitors on the IC side of the bead. This filters high-frequency noise from the rest of the supply.
Can it carry 4A of DC current?
The rated current is 4A, but impedance changes with DC bias and temperature. Keep the current within the rating and check the manufacturer datasheet for derating curves in your design.
