GY-87 10DOF IMU Module (MPU6050, HMC5883L, BMP180)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | HW-290/GY-87 10DOF MPU6050+HMC5883L+BMP180 3-axis Gyro + 3-axis Acceleration + 3-axis Magnetic Field + Air Pressure Sensor | 450 EGP550 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 450 EGP
About this product
A 10-DOF sensor breakout combining an MPU6050 accelerometer and gyroscope, an HMC5883L 3-axis magnetometer and a BMP180 barometric pressure sensor. It suits drones, balancing robots and navigation projects that need motion, heading and altitude data. An onboard LDO regulator and filters support a 3 to 5V supply.
Specifications
- Sensors
- MPU6050 (3-axis gyro + 3-axis accelerometer), HMC5883L (3-axis magnetometer), BMP180 (pressure)
- Power supply
- 3 V to 5 V
- Interface
- I2C
- MPU6050 I2C address selection
- Solder jumper (two addresses)
- Voltage regulator
- Onboard ultra-low-noise LDO
- Noise filtering
- Onboard filters for motor and high-current noise
Frequently asked questions
What is the price of GY-87 10DOF IMU Module (MPU6050, HMC5883L, BMP180) in Egypt?
GY-87 10DOF IMU Module (MPU6050, HMC5883L, BMP180) currently costs 450 EGP in Egypt.
Where can I buy GY-87 10DOF IMU Module (MPU6050, HMC5883L, BMP180) in Egypt?
GY-87 10DOF IMU Module (MPU6050, HMC5883L, BMP180) is available from Microohm. Compare the offers above to find the best price.
How do I connect the GY-87 to an Arduino?
Connect VCC to 5V (or 3.3V within the 3 to 5V range), GND to GND, and SDA and SCL to the board's I2C pins (A4 and A5 on an Uno). The three sensors appear on the I2C bus at their default addresses: MPU6050 at 0x68, HMC5883L at 0x1E and BMP180 at 0x77.
How do I change the MPU6050 address?
Close the solder jumper on the module to change the MPU6050 address from 0x68 to 0x69, which is set by the AD0 pin. This lets a second MPU6050 share the same I2C bus.
