DWIN DGUS 4.3 inch TFT LCD Module DMT48270C043_15WT with Frame
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 12 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
A 4.3 inch DWIN DGUS TFT LCD module with 480 × 272 resolution and 65K (16-bit) colours, supplied with its frame. It uses a TTL serial UART interface, so it can be controlled by any microcontroller with a serial port and designed with DWIN's GUI tool.
Specifications
- Screen size
- 4.3 inch
- Resolution
- 480 × 272
- Colour depth
- 65K (16-bit, 5R6G5B)
- Active area
- 95.0 mm × 53.9 mm
- Interface
- UART, TTL serial
- Frame
- With frame
- Brand / model
- DWIN DMT48270C043_15WT
Frequently asked questions
Is the frame included?
Yes, this listing is for the module with its frame.
How are the screens designed and controlled?
The DGUS system provides GUI design software and pre-installed commands. You design the screens with the GUI tool and control the display over the serial interface from your microcontroller.
