ST7789 2.8-inch SPI TFT LCD 320x240 Module 3.3V (UGE)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | ST7789 2.8 inch SPI LCD TFT 320×240 module 3.3V | 375 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 375 EGP
About this product
A 2.8-inch colour TFT display with 320x240 resolution, driven by the ST7789 controller over a 4-wire SPI interface. It runs at 3.3V only and suits ESP32 and Arduino projects such as dashboards, meters, IoT panels and handheld interfaces. It is commonly used with the TFT_eSPI library.
Specifications
- Screen size
- 2.8 inch
- Resolution
- 320 x 240
- Driver IC
- ST7789
- Interface
- 4-wire SPI
- Operating voltage
- 3.3 V (do not use 5 V)
- Header pins
- GND, 3V3, CS, RST, SCK, MOSI, D/C
- Backlight
- Always on (no BL pin)
Frequently asked questions
What is the price of ST7789 2.8-inch SPI TFT LCD 320x240 Module 3.3V (UGE) in Egypt?
ST7789 2.8-inch SPI TFT LCD 320x240 Module 3.3V (UGE) currently costs 375 EGP in Egypt.
Where can I buy ST7789 2.8-inch SPI TFT LCD 320x240 Module 3.3V (UGE) in Egypt?
ST7789 2.8-inch SPI TFT LCD 320x240 Module 3.3V (UGE) is available from UGE. Compare the offers above to find the best price.
How do I wire this display to an ESP32?
The listed wiring is GND to GND, 3V3 to 3.3V, CS to GPIO2, RST to GPIO13, SCK to GPIO18, MOSI to GPIO23 and D/C to GPIO12.
Can I connect it directly to a 5V Arduino Uno?
No. The module is 3.3V only and the listing warns against 5V. Use a 3.3V board, or add proper logic-level shifting and a 3.3V supply for the module.
