BC107 NPN Bipolar Transistor 45 V 100 mA
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Circuits Electronics | BC 107 Transistor NPN | 6 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 6 EGP
About this product
BC107 is a general-purpose NPN bipolar junction transistor rated for 45 V collector-emitter, 100 mA maximum DC collector current and 300 mW power dissipation. It is used for small-signal amplification and low-current switching in hobby and student circuits.
Specifications
- Polarity
- NPN
- Configuration
- Single
- Collector-emitter voltage (VCEO max)
- 45 V
- Collector-base voltage (VCBO)
- 50 V
- Emitter-base voltage (VEBO)
- 6 V
- Max DC collector current
- 0.1 A
- Power dissipation (Pd)
- 300 mW
- Operating temperature
- -55 °C to +175 °C
Frequently asked questions
What is the price of BC107 NPN Bipolar Transistor 45 V 100 mA in Egypt?
BC107 NPN Bipolar Transistor 45 V 100 mA currently costs 6 EGP in Egypt.
Where can I buy BC107 NPN Bipolar Transistor 45 V 100 mA in Egypt?
BC107 NPN Bipolar Transistor 45 V 100 mA is available from Circuits Electronics. Compare the offers above to find the best price.
What is the pinout?
Pin arrangement depends on the package style, so check the datasheet from your supplier for the exact package before wiring the emitter, base and collector.
Can it switch a relay or motor directly?
Not directly. The maximum collector current is 100 mA, so use it for small loads or as a driver stage for a larger transistor or relay driver.
