USB CNC Controller 2-Axis Stepper Driver for DIY Laser / CNC
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 13 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
A USB CNC controller board with a two-axis stepper motor driver for DIY laser engravers and small CNC machines. It supports standard XY operation as well as H-Bot kinematics, and drives 2-phase 4-wire stepper motors up to 2 A. The board measures 100 × 60 mm and is powered through a DC 5.5 × 2.1 mm jack.
Specifications
- Interface
- USB
- Axes
- 2
- Stepper support
- 2-phase 4-wire, up to 2 A
- Input voltage
- 7.5–12 V DC
- Power jack
- DC 5.5 × 2.1 mm, center positive
- Kinematics
- XY and H-Bot
- Board size
- 100 × 60 mm
Frequently asked questions
Which power supply should I use?
The listing gives a 7.5–12 V input on a DC 5.5 × 2.1 mm jack with center positive, and notes that voltage affects laser output. It also lists a power requirement above 12 V, 2 A, so check the board label and listing before connecting.
Does it support H-Bot kinematics?
Yes. The listing says it supports both standard XY mode and the new H-Bot mode.
