Tiny A4988/DRV8825 4-Axis Stepper Driver Base Board for NEMA17
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | Tiny A4988 DRV8825 Extension 4 axis Driver Base Board for Stepper Motor Nema17 | 175 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 175 EGP
About this product
A base board that accepts an A4988 or DRV8825 stepper driver module and brings out its signal, motor and power connections for NEMA17 stepper motors. Header selection gives 16 microsteps with the A4988 or 32 with the DRV8825, and it is used in 3D printer and CNC builds.
Specifications
- Compatible drivers
- A4988, DRV8825
- Microstepping
- 16 (A4988) / 32 (DRV8825), selected by 2x3 header
- Motor connector
- 1x4 pin header
- Power connector
- 1x3 pin header: GND, 5V, VM
- Signal pins
- DIR, STP, EN
- Motor type
- NEMA17 stepper motor
Frequently asked questions
What is the price of Tiny A4988/DRV8825 4-Axis Stepper Driver Base Board for NEMA17 in Egypt?
Tiny A4988/DRV8825 4-Axis Stepper Driver Base Board for NEMA17 currently costs 175 EGP in Egypt.
Where can I buy Tiny A4988/DRV8825 4-Axis Stepper Driver Base Board for NEMA17 in Egypt?
Tiny A4988/DRV8825 4-Axis Stepper Driver Base Board for NEMA17 is available from UGE. Compare the offers above to find the best price.
How should I insert the driver module?
Insert the A4988 or DRV8825 in the correct orientation. The listing warns that a reversed driver may be burned, and the board may be damaged as well. Check the marking on the board and the driver before applying power.
How do I select the microstepping mode and wire the power?
Use the 2x3 pin header to select the subdivision: 16 for the A4988 or 32 for the DRV8825. Connect the 1x3 header to GND, 5V and VM as labeled, and the 1x4 header to the stepper motor cable. Control the driver through the DIR, STP and EN pins.
