U2164D 64K-bit DRAM IC 150ns DIP-16
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | U2164D 4x16K RAM IC DIP 16-Pin | 30 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 30 EGP
About this product
The U2164D is a 64K-bit dynamic RAM (64K x 1) in a 16-pin DIP package with a 150 ns access time. It requires 128 refresh cycles every 2 ms and is mainly used in vintage computers and retro electronics projects.
Specifications
- Type
- Dynamic RAM (DRAM)
- Capacity
- 64K bit (64K x 1)
- Access time
- 150 ns
- Refresh
- 128 cycles every 2 ms
- Package
- DIP-16
Frequently asked questions
What is the price of U2164D 64K-bit DRAM IC 150ns DIP-16 in Egypt?
U2164D 64K-bit DRAM IC 150ns DIP-16 currently costs 30 EGP in Egypt.
Where can I buy U2164D 64K-bit DRAM IC 150ns DIP-16 in Egypt?
U2164D 64K-bit DRAM IC 150ns DIP-16 is available from Makers Electronics. Compare the offers above to find the best price.
Does the U2164D run from a single 5V supply?
It depends on the version. The original 2164 uses +12V, +5V and -5V rails, while the 2164A variant runs from +5V only. Check the exact marking and datasheet before powering it.
Can I interface it directly with a microcontroller?
Not easily. DRAM needs multiplexed row and column addresses and periodic refresh, so it requires a memory controller. For microcontroller projects, SRAM or SPI RAM is simpler.
