TMP36GT9Z Analog Temperature Sensor, TO-92 Package
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
| Ekostra | LM35DZ Temperature Sensor Chinese | 75 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 75 EGP
About this product
The TMP36GT9Z is an analog temperature sensor from Analog Devices in a TO-92 package. It outputs a voltage that rises linearly with temperature, about 10 mV per °C with a 500 mV offset at 0 °C, so a microcontroller ADC can read it directly. It is sold as an alternative to the LM35DZ, but the offset means code written for the LM35 needs adjusting.
Specifications
- Output type
- Analog voltage
- Output sensitivity
- 10 mV/°C
- Output at 0 °C
- 500 mV
- Temperature range
- -40 °C to +125 °C
- Supply voltage
- 2.7 V to 5.5 V
- Package
- TO-92
Frequently asked questions
What is the price of TMP36GT9Z Analog Temperature Sensor, TO-92 Package in Egypt?
TMP36GT9Z Analog Temperature Sensor, TO-92 Package currently costs 75 EGP in Egypt.
Where can I buy TMP36GT9Z Analog Temperature Sensor, TO-92 Package in Egypt?
TMP36GT9Z Analog Temperature Sensor, TO-92 Package is available from Ekostra. Compare the offers above to find the best price.
Can I use it as a direct replacement for the LM35DZ?
Not without code changes. The TMP36 outputs 500 mV at 0 °C, while the LM35 outputs 0 V at 0 °C. Subtract the offset in firmware, using T = (Vout - 0.5) / 0.01 in °C.
How do I wire it to an Arduino or ESP32?
Connect the supply pin to a supply within 2.7 V to 5.5 V, the output pin to an analog input such as A0 or an ADC pin, and the ground pin to GND. Check the datasheet for the exact pin order of the TO-92 package before wiring.
