PS2 Joystick Module Breakout Sensor 5V
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | PS2 Joystick Module Breakout Sensor High Quality | 38 EGP45 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 38 EGP
About this product
A PS2-style analog joystick module with two potentiometer axes (X and Y) and a push button. It is used in game controllers, robot control, menu navigation and other Arduino or microcontroller projects. Its 2.54 mm pin headers fit breadboards and standard headers, and it operates at 5V.
Specifications
- Dimensions
- 34 × 34 × 15 mm
- Weight
- 10 g (without hat)
- Operating voltage
- 5 V
- Pin pitch
- 2.54 mm
- Outputs
- Analog X, Analog Y, digital push button
Frequently asked questions
What is the price of PS2 Joystick Module Breakout Sensor 5V in Egypt?
PS2 Joystick Module Breakout Sensor 5V currently costs 38 EGP in Egypt.
Where can I buy PS2 Joystick Module Breakout Sensor 5V in Egypt?
PS2 Joystick Module Breakout Sensor 5V is available from Microohm. Compare the offers above to find the best price.
How do I wire it to an Arduino Uno?
Connect GND to GND and VCC to 5V. Connect VRX to analog input A0, VRY to A1, and SW to a digital pin such as D2 using INPUT_PULLUP in code. Read the axes with analogRead and the button as active low.
Can I use it with 3.3V boards such as ESP32?
The module is rated at 5V, and its analog outputs can reach 5V when powered from 5V. Do not connect them directly to ESP32 pins, which accept up to 3.3V. Use a voltage divider or a level shifter, and check the datasheet.
