Power Latching Relay Double Coil 80A 250VAC 12VDC
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | Power Latching Relay Double Coil 80A 250VAC WL09VA-F-112DM | 180 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 180 EGP
About this product
A sealed, single-pole latching power relay with double coils, rated 80 A at 250 VAC with a 12 VDC coil. It holds its contact state after a short coil pulse, so it draws no continuous coil power. Intended for household appliances, automation systems and electronic equipment.
Specifications
- Part number
- WL09VA-F-112DM
- Coil voltage
- 12VDC / 12 فولت تيار مستمر
- Contact rating
- 80A 250VAC / 80 أمبير 250 فولت تيار متردد
- Coil type
- Double coil (latching) / ملفان (Latching)
- Number of poles
- 1
- Dimensions
- 39 x 30 x 17.5 mm
- Protection
- Sealed / مختوم
Frequently asked questions
What is the price of Power Latching Relay Double Coil 80A 250VAC 12VDC in Egypt?
Power Latching Relay Double Coil 80A 250VAC 12VDC currently costs 180 EGP in Egypt.
Where can I buy Power Latching Relay Double Coil 80A 250VAC 12VDC in Egypt?
Power Latching Relay Double Coil 80A 250VAC 12VDC is available from Makers Electronics. Compare the offers above to find the best price.
How do I wire the two coils?
Apply a 12 V DC pulse to one coil to set the contacts and to the other coil to reset them. Do not keep either coil energized continuously. Confirm the set and reset terminal labels in the manufacturer's datasheet before wiring.
Can it switch DC loads?
The listing gives the electricity type as AC and the contact rating as 250 VAC. Check the datasheet for DC contact ratings before switching any DC load.
