MCP2551 High-Speed CAN Transceiver DIP-8
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Future Electronics | MCP2551 CAN-BUS TRANSCEIVER | 460 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 460 EGP
About this product
The MCP2551 is a high-speed CAN transceiver that converts the TX and RX logic signals of a microcontroller or CAN controller into the differential CANH and CANL lines of a CAN bus. It implements CAN 2.0B at up to 1 Mb/s and supports up to 112 nodes on one bus.
Specifications
- CAN standard
- CAN V2.0B
- Maximum data rate
- 1 Mb/s
- Maximum nodes on bus
- 112
- Supply voltage
- 5 V (4.5-5.5 V)
- Package
- DIP-8
- Bus lines
- CANH, CANL
Frequently asked questions
What is the price of MCP2551 High-Speed CAN Transceiver DIP-8 in Egypt?
MCP2551 High-Speed CAN Transceiver DIP-8 currently costs 460 EGP in Egypt.
Where can I buy MCP2551 High-Speed CAN Transceiver DIP-8 in Egypt?
MCP2551 High-Speed CAN Transceiver DIP-8 is available from Future Electronics. Compare the offers above to find the best price.
Do I need a CAN controller as well as the MCP2551?
Yes. The MCP2551 is only a transceiver. It needs a CAN controller, either built into a microcontroller or external, such as the MCP2515 connected over SPI.
How is the MCP2551 wired on a CAN bus?
Connect TXD and RXD to the controller's CAN TX and RX pins, connect CANH and CANL to the bus lines, and supply 5 V with a common ground. Place 120 Ω termination resistors at each end of the bus, and tie the Rs pin to ground for maximum speed.
