LED Bar Array with Two-Digit 7-Segment Display 0.36 inch
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 12 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
A multi-element LED module listed as a dual 0.36-inch seven-segment display combined with a bar graph array of 14 individual red LEDs in one package. It suits digital readouts, signal strength and power status indicators in prototypes and finished products. The listing also mentions red, yellow and green color options.
Specifications
- Digit height
- 0.36 inch
- Digits
- 2 (7-segment)
- Bar graph elements
- 14 red LEDs
- Forward current per segment
- 25 mA
- Max reverse voltage
- 5 V
- Colors
- Red, yellow, green (as listed)
Frequently asked questions
How should I limit the current?
The listed maximum forward current is 25 mA per segment. Use a series resistor for each segment or a driver IC, and calculate the resistor value from the supply voltage and the LED forward voltage.
How do I identify the pinout?
The listing does not give a pinout. Check the manufacturer's datasheet, or use a multimeter in diode mode to find each segment and determine whether the display is common anode or common cathode.
