L293D Motor Drive Shield Expansion Board (K293)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 MicroohmCheapest | Mini Motor Drive Shield Expansion Board L293D Module | 70 EGP85 | View in store |
 RAM Electronics | L293D Expansion Board Module (SKU#K293) | 75 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 70 EGP
About this product
The L293D motor drive shield is an expansion board built around the L293D dual H-bridge driver IC. It drives two DC motors or one bipolar stepper motor in both directions, with enable control and overtemperature protection, for robot and maker projects.
Specifications
- Driver IC
- L293D (dual H-bridge)
- Input voltage (motor supply)
- DC 4.5 V to 25 V
- Output current per channel
- 600 mA
- Peak output current per channel (non-repetitive)
- 1.2 A
- Logic 0 input voltage
- Up to 1.5 V
- Protection
- Overtemperature protection
- Control
- Enable facility
Frequently asked questions
What is the price of L293D Motor Drive Shield Expansion Board (K293) in Egypt?
L293D Motor Drive Shield Expansion Board (K293) currently costs between 70 and 75 EGP across 2 offers in Egypt.
Where can I buy L293D Motor Drive Shield Expansion Board (K293) in Egypt?
L293D Motor Drive Shield Expansion Board (K293) is available from Microohm and RAM Electronics. Compare the offers above to find the best price.
Can I run 12 V motors with this shield?
Yes, within the 4.5 V to 25 V input range. Keep the current per channel at or below 600 mA continuous (1.2 A non-repetitive peak). Higher-current motors need a more powerful driver.
How do I connect it to my controller board?
The board is sold as a shield, so check its header layout against your controller before stacking it. Then use the enable and direction input pins to set each motor's speed and direction in your code.
