IR2112 High and Low Side Gate Driver IC DIP-14
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | IR2112 High and Low Side Driver IC DIP-14 (Brand: International Rectifier) | 95 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 95 EGP
About this product
The IR2112 is a high- and low-side gate driver IC in a 14-pin DIP package, with a shutdown input. It drives two N-channel MOSFETs or IGBTs in a half-bridge, as used in motor drivers, inverters and class-D stages. The high-side output floats on a bootstrap supply and is commonly fed from a microcontroller PWM signal.
Specifications
- Driver type
- High-side and low-side
- Package
- 14-pin DIP
- Supply voltage (VCC)
- 10 V to 20 V
- High-side floating voltage
- Up to 600 V
- Output current
- 2 A source / 2 A sink (typical)
- Shutdown input
- Yes (SD)
Frequently asked questions
What is the price of IR2112 High and Low Side Gate Driver IC DIP-14 in Egypt?
IR2112 High and Low Side Gate Driver IC DIP-14 currently costs 95 EGP in Egypt.
Where can I buy IR2112 High and Low Side Gate Driver IC DIP-14 in Egypt?
IR2112 High and Low Side Gate Driver IC DIP-14 is available from Makers Electronics. Compare the offers above to find the best price.
How do I wire the IR2112 to a microcontroller?
Feed the HIN and LIN inputs from two PWM outputs of the microcontroller, and connect the high-side supply through a bootstrap capacitor and diode. Pulling SD high disables both outputs.
Why is a bootstrap capacitor needed?
The high-side driver's supply floats with the switching node, so a bootstrap capacitor charged through a diode from VCC provides its local supply during each on-cycle.
