AD524 Instrumentation Amplifier, Ceramic DIP-16
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 12 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
AD524 is a precision monolithic instrumentation amplifier from Analog Devices, intended for data acquisition systems that need high accuracy, high common-mode rejection and low offset drift. It is supplied in a 16-pin ceramic DIP package, with pin-programmable gains of 1, 10, 100 and 1000 and a 25 MHz gain-bandwidth product.
Specifications
- Noise
- 0.3 µV p-p (0.1 Hz to 10 Hz)
- Nonlinearity
- 0.003% (G = 1)
- CMRR
- 120 dB (G = 1000)
- Input offset voltage
- 50 µV
- Offset voltage drift
- 0.5 µV/°C
- Gain bandwidth product
- 25 MHz
- Pin-programmable gains
- 1, 10, 100, 1000
- Package
- 16-pin ceramic DIP
Frequently asked questions
What is the AD524 used for?
It is used in data acquisition systems that require high accuracy, such as amplifying small differential signals from transducers.
Which gains are available?
Gains are pin-programmable to 1, 10, 100 and 1000.
