5mm Red LED 2.0V 20mA Max
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | LED Red 5mm | 1 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 1 EGP
About this product
Basic 5mm through-hole LED with a red lens, commonly used for power indication, pin status and simple displays. Typical forward voltage is 2.0 V with a maximum current of 20 mA, and the suggested operating current for this part is 16 to 18 mA.
Specifications
- Package
- 5 mm through-hole / 5 مم ثقب عابر
- Lens color
- Red / أحمر
- Forward voltage
- 1.8 to 2.2 V (typical 2.0 V) / 1.8 إلى 2.2 فولت (النموذجي 2.0 فولت)
- Max current
- 20 mA
- Suggested current
- 16 to 18 mA / 16 إلى 18 mA
- Luminous intensity
- 150 to 200 mcd / 150 إلى 200 mcd
Frequently asked questions
What is the price of 5mm Red LED 2.0V 20mA Max in Egypt?
5mm Red LED 2.0V 20mA Max currently costs 1 EGP in Egypt.
Where can I buy 5mm Red LED 2.0V 20mA Max in Egypt?
5mm Red LED 2.0V 20mA Max is available from UGE. Compare the offers above to find the best price.
What series resistor should I use with a 5 V supply?
At 17 mA and 2.0 V forward voltage, R = (5 - 2.0) / 0.017 is about 176 ohms. Use the nearest standard value, 180 ohms. Never connect the LED to a supply without a resistor.
Can it be driven from a 3.3 V microcontroller pin?
Yes, with a series resistor. At 17 mA and 2.0 V forward voltage, R = (3.3 - 2.0) / 0.017 is about 76 ohms, so 75 or 82 ohms is a reasonable choice. Check the output current limit of your microcontroller pin.
