Yellow LED 3mm Diffused (20mA max)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | LED Yellow Color 3mm | 0.5 EGP0.8 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 0.5 EGP
About this product
A standard 3mm yellow LED with a diffused lens, used for status indication, pin monitoring and basic display projects. Its forward drop is 2.0 to 2.4V, with a maximum current of 20mA and a suggested operating current of 16 to 18mA. It is a good choice for general-purpose indicator lights in electronics prototypes.
Specifications
- Color
- Yellow
- Lens diameter
- 3 mm
- Lens type
- Diffused
- Forward voltage
- 2.0 - 2.4 V
- Maximum current
- 20 mA
- Suggested current
- 16 - 18 mA
- Luminous intensity
- 40 - 100 mcd
Frequently asked questions
What is the price of Yellow LED 3mm Diffused (20mA max) in Egypt?
Yellow LED 3mm Diffused (20mA max) currently costs 0.5 EGP in Egypt.
Where can I buy Yellow LED 3mm Diffused (20mA max) in Egypt?
Yellow LED 3mm Diffused (20mA max) is available from Microohm. Compare the offers above to find the best price.
What series resistor should I use with a 5V supply?
With a 5V supply and about 2.2V forward drop, a 150 ohm resistor gives roughly 15 to 18 mA.
Why does the yellow LED need a different resistor than the red one?
Yellow LEDs have a higher forward voltage (2.0 to 2.4V versus 1.8 to 2.2V for red), so the same resistor gives a different current. Calculate the resistor from the supply voltage and the LED's forward drop.
