2N5401 High-Voltage PNP Bipolar Transistor (150V, 0.6A, TO-92)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Future ElectronicsCheapest | 2N5401 Transistor (150V, 0.6A) | 1 EGP | View in store |
 Makers Electronics | 2N5401 High Current PNP Bipolar Transistor | 1 EGP | View in store |
 RAM Electronics | Transistor 2N5401 | 2 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 1 EGP
About this product
The 2N5401 is a PNP bipolar transistor designed for high-voltage, low-power switching and amplification. It is supplied in a TO-92 package and its complementary NPN type is the 2N5551, which makes it suitable for push-pull stages.
Specifications
- Transistor type
- PNP bipolar / PNP ثنائي القطب
- Collector-emitter voltage (VCEO)
- 150 V / 150 فولت
- Continuous collector current (IC)
- 0.6 A / 0.6 أمبير
- DC current gain (hFE)
- Up to 100 / حتى 100
- Complementary NPN type
- 2N5551 / 2N5551
- Package
- TO-92 / TO-92
- Lead-free package
- Yes / نعم
Frequently asked questions
What is the price of 2N5401 High-Voltage PNP Bipolar Transistor (150V, 0.6A, TO-92) in Egypt?
2N5401 High-Voltage PNP Bipolar Transistor (150V, 0.6A, TO-92) currently costs between 1 and 2 EGP across 3 offers in Egypt.
Where can I buy 2N5401 High-Voltage PNP Bipolar Transistor (150V, 0.6A, TO-92) in Egypt?
2N5401 High-Voltage PNP Bipolar Transistor (150V, 0.6A, TO-92) is available from Future Electronics, Makers Electronics, and RAM Electronics. Compare the offers above to find the best price.
When should I choose the 2N5401 instead of the 2N3906?
The 2N5401 has a much higher collector-emitter rating (150 V compared with 40 V for the 2N3906) and a higher collector current rating (0.6 A compared with 0.2 A). Choose it for switching circuits that operate at higher voltages.
Can the 2N5401 be paired with the 2N5551 in a push-pull stage?
Yes. The 2N5551 is its NPN complement, so the two can be combined in a push-pull arrangement with their bases driven from the same signal. Check the base-drive requirements and the ratings in the datasheet for your design.
