Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | Zener diode 4.7V 1.3w 1N4732A | 1 EGP2 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 1 EGP
About this product
The 1N4732A is a 4.7 V Zener diode from the 1N47xxA series, used for voltage reference, simple shunt regulation and overvoltage clamping. It conducts in reverse breakdown once the reverse voltage reaches its Zener voltage, so it needs a series resistor in circuit.
Specifications
- Zener voltage
- 4.7 V
- Tolerance
- ±5%
- Package
- DO-41 (axial)
- Series
- 1N47xxA
Frequently asked questions
What is the price of Zener Diode 4.7V 1N4732A in Egypt?
Zener Diode 4.7V 1N4732A currently costs 1 EGP in Egypt.
Where can I buy Zener Diode 4.7V 1N4732A in Egypt?
Zener Diode 4.7V 1N4732A is available from Microohm. Compare the offers above to find the best price.
How do I connect the Zener diode?
Connect it in reverse bias, with the cathode (marked by the band) to the positive rail and the anode to ground or the reference node, through a series resistor.
How do I size the series resistor?
Use R = (Vin − Vz) / Iz, where Vin is the supply voltage, Vz is 4.7 V and Iz is the Zener current you want. Choose Iz large enough for regulation but within the diode's power limit.
