USB Type-C Female Connector (DIP)
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Circuits Electronics | USB Type C Female Connector | 10 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 10 EGP
About this product
A USB Type-C female receptacle with DIP pins for through-hole soldering onto PCBs and prototype boards. It is used in DIY projects that need a USB-C power or data port, such as small power boards and custom development boards. The listing specifies only the DIP connection type.
Specifications
- Connector type
- USB Type-C female
- Mounting
- DIP (through-hole)
- Connection
- DIP
Frequently asked questions
What is the price of USB Type-C Female Connector (DIP) in Egypt?
USB Type-C Female Connector (DIP) currently costs 10 EGP in Egypt.
Where can I buy USB Type-C Female Connector (DIP) in Egypt?
USB Type-C Female Connector (DIP) is available from Circuits Electronics. Compare the offers above to find the best price.
Does this connector alone provide USB Power Delivery?
No. The receptacle only provides the physical port. A USB-C sink needs 5.1 kΩ pull-down resistors on both CC1 and CC2 to request 5 V, and higher power needs a USB-PD controller.
How do I wire it for a simple USB-C power input?
Connect VBUS to the power input, GND to ground, and CC1 and CC2 each through a 5.1 kΩ resistor to ground. D+ and D- are used only if you need data. Verify the pinout of your specific part before soldering.
