UNI-ROYAL 4D03WGJ0103T5E Resistor Network Array 10kΩ ±5% 0603x4
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | Resistor Network Array SMD ±5% 10kΩ 62.5mW ±200ppm/℃ 0603×4 | 0.85 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 0.85 EGP
About this product
A surface-mount resistor network from UNI-ROYAL containing four 10kΩ resistors in a compact 0603×4 package. Each element is rated at 62.5mW with ±5% tolerance and a ±200ppm/℃ temperature coefficient. Typically used for pull-up or pull-down sets on digital inputs and in space-constrained PCB designs.
Specifications
- Resistance per element
- 10kΩ
- Number of resistors
- 4
- Tolerance
- ±5%
- Power rating per element
- 62.5mW
- Temperature coefficient
- ±200ppm/℃
- Package
- 0603×4
- Mounting
- SMD
Frequently asked questions
What is the price of UNI-ROYAL 4D03WGJ0103T5E Resistor Network Array 10kΩ ±5% 0603x4 in Egypt?
UNI-ROYAL 4D03WGJ0103T5E Resistor Network Array 10kΩ ±5% 0603x4 currently costs 0.85 EGP in Egypt.
Where can I buy UNI-ROYAL 4D03WGJ0103T5E Resistor Network Array 10kΩ ±5% 0603x4 in Egypt?
UNI-ROYAL 4D03WGJ0103T5E Resistor Network Array 10kΩ ±5% 0603x4 is available from Makers Electronics. Compare the offers above to find the best price.
Can I use it as pull-up or pull-down resistors on a microcontroller input?
Yes, 10kΩ is a common value for pull-up or pull-down resistors on digital inputs. Confirm the pinout in the UNI-ROYAL datasheet for 4D03WGJ0103T5E before soldering, because resistor arrays can have different internal connections.
How do I check that the power rating is enough for my circuit?
Calculate the power in each element as P = V²/R. For example, 5V across 10kΩ dissipates about 2.5mW, far below the 62.5mW rating. The rating allows up to about 25V across a single element.
