TP4056 1A Lithium Battery Charger Module with Protection
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 MicroohmCheapest | TP4056 Lithium Battery Charger Module with Micro USB & Protection | 17.5 EGP25 | View in store |
 Makers Electronics | TP4056 TYPE-C Lithium Battery Charging Board Module 1A with Battery Protection | 18 EGP | View in store |
 UGE | USB 5V 1A 18650 Lithium Battery Charger TP4056 Board With Over Discharge Protection Module | 25 EGP | View in store |
 RAM Electronics | TP4056 USB Type C Lithium Battery Charger Module 1A With Battery Protection | 25 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 17.5 EGP
About this product
A single-cell lithium-ion and LiPo charger module based on the TP4056 linear charging chip, with a default charge current of 1 A and a 4.2 V full-charge voltage. It includes over-discharge protection for the battery and shows status with a red LED while charging and a green LED when full. Available with Micro USB or USB Type-C input, it suits 18650 and similar single-cell projects.
Specifications
- Charging IC
- TP4056
- Input voltage
- 4.5 V – 5.5 V
- Charge current
- 1 A (adjustable)
- Full-charge voltage
- 4.2 V
- Protection
- Over-discharge protection
- Input connector
- Micro USB or USB Type-C (depends on variant)
- Operating temperature
- -10 °C to +85 °C
- Size
- 25 x 19 x 6 mm
Frequently asked questions
What is the price of TP4056 1A Lithium Battery Charger Module with Protection in Egypt?
TP4056 1A Lithium Battery Charger Module with Protection currently costs between 17.5 and 25 EGP across 4 offers in Egypt.
Where can I buy TP4056 1A Lithium Battery Charger Module with Protection in Egypt?
TP4056 1A Lithium Battery Charger Module with Protection is available from Microohm, Makers Electronics, UGE, and RAM Electronics. Compare the offers above to find the best price.
How do I connect the battery to the TP4056 module?
Connect the single-cell battery to the BAT+ and BAT- pads and power the module from 5 V USB on the IN+ and IN- pads. Pad labels differ between boards, so check the silkscreen before connecting.
Can it charge LiFePO4 batteries?
No. The TP4056 is designed for single-cell Li-ion and LiPo cells with a 4.2 V full-charge voltage. LiFePO4 cells need a different charge voltage of about 3.6 V and require a suitable charger.
