TLC7524CN 8-Bit CMOS Multiplying DAC PDIP-16
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
| Circuits Electronics | TLC7524CN (DAC-10 Bit) | 130 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 130 EGP
About this product
The TLC7524CN is a CMOS 8-bit multiplying digital-to-analog converter with input latches, designed for easy interfacing with common microprocessor buses. It operates from a single 5V to 15V supply and offers accuracy to 1/2 LSB without laser trimming. It is used to convert digital values into analog signals in control, measurement and signal generation projects.
Specifications
- Resolution
- 8-bit
- Supply voltage
- 5V to 15V
- Accuracy
- 1/2 LSB
- Typical power dissipation
- less than 5mW
- Technology
- CMOS, multiplying DAC with input latches
- Package
- PDIP-16 (16-pin plastic DIP)
Frequently asked questions
What is the price of TLC7524CN 8-Bit CMOS Multiplying DAC PDIP-16 in Egypt?
TLC7524CN 8-Bit CMOS Multiplying DAC PDIP-16 currently costs 130 EGP in Egypt.
Where can I buy TLC7524CN 8-Bit CMOS Multiplying DAC PDIP-16 in Egypt?
TLC7524CN 8-Bit CMOS Multiplying DAC PDIP-16 is available from Circuits Electronics. Compare the offers above to find the best price.
Is the TLC7524CN an 8-bit or 10-bit DAC?
It is an 8-bit DAC. The listing title says 10 Bit, but the device description and the TLC7524 datasheet describe an 8-bit converter. Check the datasheet before designing around the resolution.
How do I get a voltage output from it?
The TLC7524 is a current-output R-2R ladder DAC. Connect its output current to an operational amplifier configured as a current-to-voltage converter, with a feedback resistor, to produce a usable analog voltage. It also needs 8 data lines plus control lines from the microcontroller.
