TIP34C PNP Power Transistor 100V 10A TO-247
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | Tip34C PNP Transistor 100V 10A | 30 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 30 EGP
About this product
The TIP34C is a PNP power transistor rated 100 V and 10 A, with 80 W power dissipation and a 3 MHz transition frequency. It comes in a TO-218AC or TO-247 package. It is used in audio amplifiers, power switching and motor or relay drivers, and it is the complement of the NPN TIP33C.
Specifications
- Transistor type
- PNP
- Collector-emitter breakdown voltage (max)
- 100 V
- Collector current (Ic max)
- 10 A
- Power dissipation (max)
- 80 W
- DC current gain (hFE min)
- 20 @ 3 A, 4 V
- Transition frequency
- 3 MHz
- Package
- TO-218AC / TO-247 (3P)
Frequently asked questions
What is the price of TIP34C PNP Power Transistor 100V 10A TO-247 in Egypt?
TIP34C PNP Power Transistor 100V 10A TO-247 currently costs 30 EGP in Egypt.
Where can I buy TIP34C PNP Power Transistor 100V 10A TO-247 in Egypt?
TIP34C PNP Power Transistor 100V 10A TO-247 is available from Makers Electronics. Compare the offers above to find the best price.
Can the TIP34C replace a TIP36C?
Not always. Both are 100 V PNP transistors, but the TIP36C is rated for 25 A and the TIP34C for 10 A, and their gain and saturation figures differ. Check the datasheet and current requirement before substituting one for the other.
What is the pinout of the TIP34C?
Pin 1 is the base, pin 2 is the collector and pin 3 is the emitter. The metal tab is also connected to the collector.
