STC8G1K17-38I-TSSOP20 8051 Microcontroller, 17KB Flash
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | STC Microcontroller STC8G1K17-38I-TSSOP20 | 49.02 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 49.02 EGP
About this product
STC8G1K17 is an 8051-core microcontroller from STC with 17KB program flash, 1.25KB RAM and 4KB data EEPROM/flash. It offers UART, I2C and SPI, 10-bit PWM, two 16-bit timers, a comparator and low-voltage detection. It operates from 1.9V to 5.5V over -40°C to +85°C, suiting compact embedded control and sensor projects.
Specifications
- Program flash
- 17 KB
- RAM
- 1.25 KB
- Data EEPROM/flash
- 4 KB
- Supply voltage
- 1.9 V to 5.5 V
- Operating temperature
- -40 °C to +85 °C
- GPIO ports
- 6
- Serial interfaces
- UART x1, I2C x1, SPI x1
- PWM
- 10-bit, 6 channels
Frequently asked questions
What is the price of STC8G1K17-38I-TSSOP20 8051 Microcontroller, 17KB Flash in Egypt?
STC8G1K17-38I-TSSOP20 8051 Microcontroller, 17KB Flash currently costs 49.02 EGP in Egypt.
Where can I buy STC8G1K17-38I-TSSOP20 8051 Microcontroller, 17KB Flash in Egypt?
STC8G1K17-38I-TSSOP20 8051 Microcontroller, 17KB Flash is available from UGE. Compare the offers above to find the best price.
Which programmer do I need for the STC8G1K17?
STC8G series chips are programmed through their built-in UART ISP bootloader, so a USB-to-serial adapter and the vendor's STC-ISP tool are usually enough. Connect the adapter's TX to the chip's RX pin and its RX to the chip's TX pin, and share a common ground.
Can it run on 3.3V?
Yes. The supply range is 1.9V to 5.5V, so 3.3V operation is within specification. Check the datasheet for GPIO voltage levels and the maximum clock your design needs.
