SN74HC595 8-Bit Shift Register with 3-State Output
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | SN74HC595 8-Bit Shift Registers With 3-State Output | 17.1 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 17.1 EGP
About this product
The SN74HC595 is an 8-bit serial-in, parallel-out shift register with a storage latch and 3-state outputs. It lets a microcontroller drive eight outputs, such as a 7-segment display or relays, using only three pins. Multiple chips can be cascaded for more outputs.
Specifications
- Type
- 8-bit serial-in, parallel-out shift register
- Outputs
- 8, 3-state with storage latch
- Logic family
- HC CMOS
- Supply voltage
- 2 V to 6 V
- Control pins
- SER, SRCLK, RCLK, OE (active-low)
Frequently asked questions
What is the price of SN74HC595 8-Bit Shift Register with 3-State Output in Egypt?
SN74HC595 8-Bit Shift Register with 3-State Output currently costs 17.1 EGP in Egypt.
Where can I buy SN74HC595 8-Bit Shift Register with 3-State Output in Egypt?
SN74HC595 8-Bit Shift Register with 3-State Output is available from UGE. Compare the offers above to find the best price.
How do I connect it to an Arduino?
Use three Arduino pins for data (SER), shift clock (SRCLK) and latch (RCLK). Send the bits with shiftOut() and then pulse the latch so the outputs update together.
Do I need to connect OE and SRCLR?
OE is active-low, so tie it to GND to enable the outputs. SRCLR (MR) is also active-low, so tie it to VCC to prevent the register from being cleared unintentionally.
