SKiiP 36NAB126V1 Semikron 1200V 70A 3-Phase IGBT Module
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 13 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
SKiiP 36NAB126V1 is a Semikron power module that integrates a three-phase bridge rectifier, a brake chopper and a three-phase bridge inverter, using fast Trench IGBTs. It is designed for inverters up to about 36 kVA, with a typical motor power of 18.5 kW. Its spring contacts provide reliable electrical connections in industrial power electronics.
Specifications
- Voltage rating
- 1200 V
- Current rating
- 70 A
- Topology
- 3-phase rectifier + brake chopper + 3-phase inverter
- IGBT technology
- Fast Trench IGBT
- Target inverter power
- Up to 36 kVA
- Typical motor power
- 18.5 kW
Frequently asked questions
What is it used for?
The listing targets inverters up to 36 kVA and typical motor drives around 18.5 kW, which makes it suitable for industrial motor drive and inverter designs.
Does it need external gate drivers?
Check the Semikron SKiiP datasheet before wiring. SKiiP modules are built with integrated driver circuitry, so confirm the required supply and control interface, as well as the DC link and protection requirements.
