Resistor Network 4.7kΩ x8 Bussed SIP-9
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | Resistor Network Array 4.7K 9Pin | 4.56 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 4.56 EGP
About this product
Single in-line resistor network containing eight 4.7 kΩ resistors that share one common terminal on pin 6, marked with a black dot. Useful as pull-up or pull-down resistors on microcontroller input lines, and saves board space compared with discrete resistors.
Specifications
- Resistance per element
- 4.7 kΩ / 4.7 كيلو أوم
- Number of resistors
- 8 / 8
- Pin count
- 9 / 9
- Common pin
- Pin 6, marked with a black dot / السن 6، ويُميَّز بنقطة سوداء
- Package
- SIP (single in-line) / أحادية الصف
Frequently asked questions
What is the price of Resistor Network 4.7kΩ x8 Bussed SIP-9 in Egypt?
Resistor Network 4.7kΩ x8 Bussed SIP-9 currently costs 4.56 EGP in Egypt.
Where can I buy Resistor Network 4.7kΩ x8 Bussed SIP-9 in Egypt?
Resistor Network 4.7kΩ x8 Bussed SIP-9 is available from UGE. Compare the offers above to find the best price.
How do I wire it as pull-up resistors?
Connect pin 6 (common) to VCC and connect each other pin to a signal line. Each line is pulled up to VCC through 4.7 kΩ when it is not driven low, such as a switch input.
Can I use it as pull-down resistors instead?
Yes. Connect pin 6 to GND instead of VCC, and each signal line will be pulled down to GND through 4.7 kΩ when it is not actively driven high.
