Relay 12V Coil 5-Pin 30A
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
| Most Electronics | Relay 12V Coil 5pin 30A O/P | 50 EGP61 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 50 EGP
About this product
A 5-pin power relay with a 12 V DC coil and contacts rated 30 A at 240 VAC (20 A at 28 VDC). Measuring 32.5 × 27.5 × 20 mm, it lets a low-current microcontroller circuit switch higher-power loads such as lamps, pumps and fans.
Specifications
- Coil voltage
- 12 V DC
- Contact rating
- 30 A @ 240 VAC / 20 A @ 28 VDC
- Number of pins
- 5
- Dimensions
- 32.5 × 27.5 × 20.0 mm
Frequently asked questions
What is the price of Relay 12V Coil 5-Pin 30A in Egypt?
Relay 12V Coil 5-Pin 30A currently costs 50 EGP in Egypt.
Where can I buy Relay 12V Coil 5-Pin 30A in Egypt?
Relay 12V Coil 5-Pin 30A is available from Most Electronics. Compare the offers above to find the best price.
Can I drive it directly from an Arduino pin?
No. The coil needs 12 V and draws more current than a microcontroller pin can supply. Use an NPN transistor or MOSFET driver powered from 12 V, with a flyback diode across the coil.
Is it suitable for switching mains voltage?
Its contacts are rated 30 A at 240 VAC, but mains wiring should only be done with proper insulation, an enclosure and safety practices, ideally by a qualified person.
