Push Button Switch 12x12x9.5mm 4-Pin Push-ON High Force
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | Press 12x12x9.5mm Push Button Switch 4 pin | 2.5 EGP3 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 2.5 EGP
About this product
This 12 x 12 mm push button switch has a 9.5 mm body height, four through-hole pins and a round shaft with a push-to-ON function. It offers a high operating force of 3.0 N or 3.6 N with a 1.05 mm travel and a rated life of 300,000 cycles, and the listing describes it as suited to automotive equipment requirements. It is useful where a firmer press is needed to avoid accidental activation.
Specifications
- Dimensions
- 12 x 12 x 9.5 mm
- Number of pins
- 4
- Mounting
- Through-hole
- Function
- Push to ON
- Operating force
- 3.0 N or 3.6 N
- Travel
- 1.05 mm
- Life
- 300,000 cycles
Frequently asked questions
What is the price of Push Button Switch 12x12x9.5mm 4-Pin Push-ON High Force in Egypt?
Push Button Switch 12x12x9.5mm 4-Pin Push-ON High Force currently costs 2.5 EGP in Egypt.
Where can I buy Push Button Switch 12x12x9.5mm 4-Pin Push-ON High Force in Egypt?
Push Button Switch 12x12x9.5mm 4-Pin Push-ON High Force is available from Microohm. Compare the offers above to find the best price.
Which pins should I connect on this 4-pin switch?
The two pins on each side are internally connected. Use one pin from each side, typically a diagonal pair, so pressing the button closes the circuit between the two sides.
What is the difference between the 3.0N and 3.6N versions?
The listing gives an operating force of 3.0N or 3.6N. The higher force version requires a firmer press, which can reduce accidental activation. Check the specific variant you receive if the operating force matters for your design.
