MB10F Full-Wave SMD Bridge Rectifier 1A 1000V
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | Full Wave SMD Bridge Rectifier MB10F 1A 1000V | 5.7 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 5.7 EGP
About this product
The MB10F is a surface-mount full-wave bridge rectifier that combines four diodes in one package to convert AC input into pulsating DC. It is rated for a 1000V reverse voltage and 1A, and suits AC-to-DC rectification in small power supplies, adapters and mains-powered circuit boards.
Specifications
- Mounting
- SMD (surface mount)
- Forward current rating
- 1A
- Reverse voltage
- 1000V
- Forward voltage VF (max)
- 1.1V
- Operating temperature
- -55 °C to 125 °C
- Weight
- 0.80 g
Frequently asked questions
What is the price of MB10F Full-Wave SMD Bridge Rectifier 1A 1000V in Egypt?
MB10F Full-Wave SMD Bridge Rectifier 1A 1000V currently costs 5.7 EGP in Egypt.
Where can I buy MB10F Full-Wave SMD Bridge Rectifier 1A 1000V in Egypt?
MB10F Full-Wave SMD Bridge Rectifier 1A 1000V is available from UGE. Compare the offers above to find the best price.
Can I connect the MB10F directly to 220V mains?
The 1000V reverse rating suits mains voltage, and the 1A rating allows somewhat more load than the MB10S. A filter capacitor is still needed after the rectifier, and any mains-connected design must include proper isolation, fusing and enclosure.
What is the difference between the MB10F and the MB10S?
Both are 1000V full-wave SMD bridge rectifiers with the same listed reverse voltage and temperature range. The MB10F is rated at 1A and the MB10S at 0.5A, so choose the MB10F when the circuit needs higher current.
