LM2596S-ADJ DC-DC Buck Converter Module 3A Adjustable
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | LM2596S-ADJ DC-DC Buck Converter 4.5-40V to 3-35V 3A Adjustable Step Down Module | 55 EGP75 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 55 EGP
About this product
The LM2596S-ADJ is an adjustable DC-DC step-down (buck) module built around the LM2596 regulator IC. It lowers a higher input voltage to a configurable output and delivers up to 3 A, which makes it suitable for powering microcontrollers, sensors and other low-voltage circuits. An onboard LED shows that power is present.
Specifications
- Input voltage
- 4.5–40 V
- Output voltage
- 1.5–35 V (adjustable)
- Maximum output current
- 3 A
- Converter type
- Step-down (Buck)
- Switching frequency
- 150 kHz
- Dimensions (L × W)
- 45 mm × 20 mm
- Indicator
- Power LED
Frequently asked questions
What is the price of LM2596S-ADJ DC-DC Buck Converter Module 3A Adjustable in Egypt?
LM2596S-ADJ DC-DC Buck Converter Module 3A Adjustable currently costs 55 EGP in Egypt.
Where can I buy LM2596S-ADJ DC-DC Buck Converter Module 3A Adjustable in Egypt?
LM2596S-ADJ DC-DC Buck Converter Module 3A Adjustable is available from Microohm. Compare the offers above to find the best price.
How do I wire the module?
Connect the source to IN+ and IN-, and the load to OUT+ and OUT-. Reversing the input or output polarity can destroy the module, so check the markings before powering it.
How do I set the output voltage?
Turn the onboard potentiometer while measuring OUT+ and OUT- with a multimeter, with the load disconnected. The input voltage must always be higher than the output you want, because this is a step-down converter and cannot boost voltage.
