Limit Switch 3-Pin NO/NC 5A 250VAC with Roller
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Microohm | Limit Switch 3 Pin N/O N/C 5A 250VAC with rolle | 10 EGP13 | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 10 EGP
About this product
A roller-lever limit switch with three pins and both normally open (NO) and normally closed (NC) contacts, rated 5 A at 250 VAC. It detects the end of travel in machines, doors and mechanical assemblies. Its compact 20 × 10 × 6 mm body fits tight enclosures.
Specifications
- Contacts
- NO and NC (3 pins)
- Rated current and voltage
- 5 A 250 VAC
- Contact resistance
- 50 mΩ
- Insulation resistance
- 100 MΩ
- Dielectric strength
- 1000 VAC / 1 min
- Mechanical life
- 1,000,000 cycles
- Body size
- 20 × 10 × 6 mm
- Pin spacing
- 8 mm / 9 mm
Frequently asked questions
What is the price of Limit Switch 3-Pin NO/NC 5A 250VAC with Roller in Egypt?
Limit Switch 3-Pin NO/NC 5A 250VAC with Roller currently costs 10 EGP in Egypt.
Where can I buy Limit Switch 3-Pin NO/NC 5A 250VAC with Roller in Egypt?
Limit Switch 3-Pin NO/NC 5A 250VAC with Roller is available from Microohm. Compare the offers above to find the best price.
How do I wire the NO and NC contacts?
Connect your load between the common pin and NO to close the circuit when the roller is pressed, or between common and NC to open it. Confirm the pin labels on the body before wiring.
Can I use it with mains voltage?
It is rated 5 A at 250 VAC. Keep the load within that rating and use insulated wiring and enclosures suited to mains work.
