L297 Stepper Motor Controller IC DIP-20
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Future ElectronicsCheapest | L297 Stepper Motor Controller IC | 20 EGP | View in store |
 Makers Electronics | L297 Motor Driver IC 4.75V~7V Parallel DIP-20 | 45 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 20 EGP
About this product
The L297 is a stepper motor controller IC that generates the phase, direction and chopping signals for bipolar and unipolar stepper motors. Paired with a dual bridge driver such as the L298N, it forms a complete interface between a microcontroller and the motor. Its current sensing and chopping features keep coil current at the desired level.
Specifications
- Package
- DIP-20
- Supply voltage
- 4.75V ~ 7V
- Supported motors
- Bipolar and unipolar stepper motors
- Current control
- Current sensing and chopping
- Companion power driver
- L298 (up to 2 A per coil)
- Control inputs
- CLOCK, CW/CCW, HALF/FULL, ENABLE, RESET
Frequently asked questions
What is the price of L297 Stepper Motor Controller IC DIP-20 in Egypt?
L297 Stepper Motor Controller IC DIP-20 currently costs between 20 and 45 EGP across 2 offers in Egypt.
Where can I buy L297 Stepper Motor Controller IC DIP-20 in Egypt?
L297 Stepper Motor Controller IC DIP-20 is available from Future Electronics and Makers Electronics. Compare the offers above to find the best price.
Does the L297 drive the motor coils by itself?
No. The L297 is a controller only. It needs a power driver such as the L298N to switch the motor coils.
Which signals does the microcontroller send to the L297?
Step pulses on CLOCK, direction on CW/CCW, step mode on HALF/FULL, plus ENABLE and RESET. The L297 converts these into the phase sequence for the driver.
