KBL1010 Bridge Rectifier 10A 1000V
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | Bridge Rectifier KBL1010 10A 1000V | 15 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 15 EGP
About this product
A single-phase KBL1010 bridge rectifier rated for 10A average forward current and 1000V repetitive peak reverse voltage. It converts AC to DC in power supplies and rectifier circuits, with a molded plastic body and RoHS-compliant leads and body.
Specifications
- Repetitive peak reverse voltage (VRRM)
- 1000 V
- RMS bridge input voltage
- 700 V
- Average forward rectified current (TC=55°C)
- 10 A
- Peak forward surge current (8.3 ms)
- 300 A
- Case
- Molded plastic
- Compliance
- RoHS
Frequently asked questions
What is the price of KBL1010 Bridge Rectifier 10A 1000V in Egypt?
KBL1010 Bridge Rectifier 10A 1000V currently costs 15 EGP in Egypt.
Where can I buy KBL1010 Bridge Rectifier 10A 1000V in Egypt?
KBL1010 Bridge Rectifier 10A 1000V is available from Makers Electronics. Compare the offers above to find the best price.
Can it be used on mains AC input?
The RMS input rating is 700V, so it can handle mains-level AC input. Mains work requires proper insulation, enclosure, and fusing. Follow electrical safety practices.
Does it need a heatsink?
At currents approaching 10A, mount it on a heatsink. The 10A rating is specified at a case temperature of 55°C, so heat removal matters.
