KA2284 Battery Level Indicator Module 5 LED 3.5-12V
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 RAM ElectronicsCheapest | Battery Power Level Indicator (SKU#KA2284) | 50 EGP | View in store |
 Makers Electronics | KA2284 Module Battery Level Indicator | 60 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 50 EGP
About this product
The KA2284 battery level indicator module uses the KA2284 chip to light up five LEDs progressively as the monitored voltage rises. It runs from 3.5 V to 12 V, and a jumper lets you choose between AC and DC input. Its level threshold is adjustable, and the compact 29 x 21 mm board suits showing the voltage level of a battery pack in DIY projects.
Specifications
- Chip
- KA2284
- Supply voltage
- 3.5 V to 12 V
- Indicator LEDs
- 5 LEDs
- Input selection
- AC or DC via jumper
- Level adjustment
- Adjustable
- PCB size
- 29 mm x 21 mm
Frequently asked questions
What is the price of KA2284 Battery Level Indicator Module 5 LED 3.5-12V in Egypt?
KA2284 Battery Level Indicator Module 5 LED 3.5-12V currently costs between 50 and 60 EGP across 2 offers in Egypt.
Where can I buy KA2284 Battery Level Indicator Module 5 LED 3.5-12V in Egypt?
KA2284 Battery Level Indicator Module 5 LED 3.5-12V is available from RAM Electronics and Makers Electronics. Compare the offers above to find the best price.
Can this module monitor a 12 V battery?
Yes, as long as the battery voltage stays within the 3.5 V to 12 V supply range. A fully charged 12 V lead-acid battery sits at the upper limit, so check the level adjustment after wiring.
What does the AC/DC jumper do?
The jumper selects whether the module reads its input as AC or DC. For a battery, set it to the DC position so the LED level reflects the battery voltage.
