IDC20 Female Socket (FC20) for 20-Pin Ribbon Cable
Part number: FC20Connectors & Headers
Currently unavailable
No store has this product in stock right now. Prices below are the last ones we recorded.
Prices updated: 13 Oct 2026
Price history
Lowest daily price, last 90 days
Not enough price history yet.
About this product
A 20-pin (2x10) IDC female socket for crimping onto a 20-conductor flat ribbon cable without soldering. It mates with a 2x10 male IDC header and is used for board-to-board and panel wiring.
Specifications
- Pins
- 20
- Layout
- 2x10
- Gender
- Female
- Termination
- IDC, ribbon cable
- Pitch
- 2.54 mm
Frequently asked questions
How do I attach it to a 20-conductor ribbon cable?
Insert the ribbon cable with the cable's stripe aligned to pin 1 of the socket, then press the cover closed using a crimping tool or a vise. Make sure the cable sits square before pressing.
Which header does it mate with?
It mates with a 2x10 (20-pin) male IDC header at 2.54 mm pitch. Align the connectors and push them together straight to avoid bent pins.
