HT12E 12-Bit Encoder IC DIP-18 (2^12 Series)
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 RAM ElectronicsCheapest | HT12E - Encoders | 35 EGP | View in store |
 Microohm | HT12E (2^12 Series of Encoders) | 40 EGP60 | View in store |
 Makers Electronics | HT-12E 12-Bit Encoder IC DIP-18 | 70 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 35 EGP
About this product
The HT12E is a 2^12 series 12-bit encoder IC used in remote control transmitters. It takes 4 data bits on AD0 to AD3 and 8 address bits, and sends the encoded serial data when the TE pin is pulled to ground. It pairs with the HT12D decoder and comes in a DIP-18 package.
Specifications
- Series
- 2^12 (12-bit)
- Address bits
- 8 (A0 to A7)
- Data inputs
- 4 (AD0 to AD3)
- Transmission enable
- TE (pin 14), active low
- Data output
- DOUT (pin 17)
- Oscillator
- RC, 1M resistor between pins 15 and 16
- Package
- DIP-18
- Operating voltage
- 2.4V to 12V
Frequently asked questions
What is the price of HT12E 12-Bit Encoder IC DIP-18 (2^12 Series) in Egypt?
HT12E 12-Bit Encoder IC DIP-18 (2^12 Series) currently costs between 35 and 70 EGP across 3 offers in Egypt.
Where can I buy HT12E 12-Bit Encoder IC DIP-18 (2^12 Series) in Egypt?
HT12E 12-Bit Encoder IC DIP-18 (2^12 Series) is available from RAM Electronics, Microohm, and Makers Electronics. Compare the offers above to find the best price.
How do I start a transmission on the HT12E?
Pull the TE pin (pin 14) to ground to enable transmission. While TE is low, the encoder sends the 12-bit frame built from AD0 to AD3 and the address pins. Hold the data inputs stable during transmission.
Can I connect the HT12E output directly to an antenna?
No. The DOUT pin is a digital serial output that drives an RF transmitter module, such as a 433 MHz ASK module, which then feeds the antenna. Connect DOUT to the transmitter data input and keep the address pattern identical to the HT12D receiver.
