CD4511 BCD to 7-Segment Decoder Driver DIP-16 Common Cathode
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 UGE | CD4511 BCD to 7 segment Common Cathode Decoder Driver DIP-16 | 39.9 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 39.9 EGP
About this product
The CD4511 is a CMOS BCD-to-7-segment latch decoder and driver for common-cathode 7-segment displays. It converts a 4-bit BCD input into segment outputs of up to 25 mA, and includes lamp test and blanking inputs. It operates from 3 V to 18 V.
Specifications
- Display type
- Common cathode / كاثود مشترك
- Supply voltage
- 3 V to 18 V / من 3 إلى 18 فولت
- Output current
- Up to 25 mA / حتى 25 مللي أمبير
- Operating temperature
- -40 °C to +85 °C / من -40 إلى +85 درجة مئوية
- Package
- DIP-16
- Features
- Lamp test, blanking / اختبار المصابيح، إخفاء العرض
Frequently asked questions
What is the price of CD4511 BCD to 7-Segment Decoder Driver DIP-16 Common Cathode in Egypt?
CD4511 BCD to 7-Segment Decoder Driver DIP-16 Common Cathode currently costs 39.9 EGP in Egypt.
Where can I buy CD4511 BCD to 7-Segment Decoder Driver DIP-16 Common Cathode in Egypt?
CD4511 BCD to 7-Segment Decoder Driver DIP-16 Common Cathode is available from UGE. Compare the offers above to find the best price.
Does it work with common-anode displays?
No, the CD4511 is designed for common-cathode displays only. A common-anode display needs a different driver, such as the CD4447.
Do I need current-limiting resistors?
Yes. Place a resistor in series with each segment output to set the current and protect the display, because the driver outputs source current into the segments.
