Bourns 3006P-1-202 Multi-Turn Trimmer 2kΩ 0.75W Through Hole
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | Trimmer Potentiometer Multi Turn 3006P-1-202 2KOhm 0.75W 3 Pins Through Hole | 7 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 7 EGP
About this product
A 15-turn cermet multi-turn trimmer potentiometer in a 0.75-inch rectangular package with a side adjustment slot. Rated 2 kΩ, 0.75 W and 400 V, it gives stable, fine adjustment for calibration in power supplies, sensor circuits and instrumentation.
Specifications
- Resistance
- 2 kΩ
- Number of turns
- 15
- Adjustment
- Side slot
- Power rating
- 750 mW (3/4 W)
- Tolerance
- 10 %
- Operating temperature
- -55 °C to +125 °C
- Element type
- Cermet
- Dimensions
- 19.05 mm x 4.83 mm x 6.35 mm
Frequently asked questions
What is the price of Bourns 3006P-1-202 Multi-Turn Trimmer 2kΩ 0.75W Through Hole in Egypt?
Bourns 3006P-1-202 Multi-Turn Trimmer 2kΩ 0.75W Through Hole currently costs 7 EGP in Egypt.
Where can I buy Bourns 3006P-1-202 Multi-Turn Trimmer 2kΩ 0.75W Through Hole in Egypt?
Bourns 3006P-1-202 Multi-Turn Trimmer 2kΩ 0.75W Through Hole is available from Makers Electronics. Compare the offers above to find the best price.
How do I read the marking 202 on this trimmer?
The code 202 means 20 followed by two zeros, which is 2,000 ohms, or 2 kΩ.
Why does it have 15 turns?
The 15 turns give fine resolution, so small changes to the screw produce small changes in resistance, which suits accurate calibration.
