BD136 PNP General Purpose Silicon Transistor TO-126
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers ElectronicsCheapest | BD136 Medium Power PNP Transistor | 2 EGP | View in store |
 Circuits Electronics | BD136 PNP Transistor | 8 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 2 EGP
About this product
The BD136 is a PNP general-purpose epitaxial silicon power transistor in a TO-126 plastic package, rated for 1.5 A collector current. It is used in amplifier stages, driver circuits and switching of small loads. It is the complementary partner of the BD135 NPN transistor.
Specifications
- Polarity
- PNP
- Package
- TO-126 (3-lead plastic)
- Collector-emitter voltage (VCEO)
- 45 V
- Collector current (IC)
- 1.5 A
- Total power dissipation (PTOT)
- 12.5 W
- Complementary type
- BD135 (NPN)
Frequently asked questions
What is the price of BD136 PNP General Purpose Silicon Transistor TO-126 in Egypt?
BD136 PNP General Purpose Silicon Transistor TO-126 currently costs between 2 and 8 EGP across 2 offers in Egypt.
Where can I buy BD136 PNP General Purpose Silicon Transistor TO-126 in Egypt?
BD136 PNP General Purpose Silicon Transistor TO-126 is available from Makers Electronics and Circuits Electronics. Compare the offers above to find the best price.
What is BD136 complementary to?
BD136 is the PNP complement of the NPN BD135, so the two are often used together in push-pull output stages.
Can it drive a relay or a motor directly?
Only within its 1.5 A collector current rating. Check the coil or motor current first, and add a flyback diode across inductive loads such as relays and motors.
