BAS16 SMD Switching Diode 75V 150mA SOT-23
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | BAS16 A6 75V 225mW Single 1V@50mA 4ns 150mA SOT-23 Switching Diode SMD | 4 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 4 EGP
About this product
BAS16 is a single switching diode in an SOT-23 SMD package with 75 V reverse voltage and 150 mA average rectified current. Its fast 6 ns reverse recovery time suits high-speed switching and signal applications.
Specifications
- Diode configuration
- Single
- Reverse voltage (Vr)
- 75V
- Average rectified current (Io)
- 150mA
- Forward voltage (Vf @ If)
- 1.25V @ 150mA
- Reverse recovery time (trr)
- 6ns
- Reverse leakage current
- 1uA @ 75V
- Power dissipation
- 225mW
- Package
- SOT-23
Frequently asked questions
What is the price of BAS16 SMD Switching Diode 75V 150mA SOT-23 in Egypt?
BAS16 SMD Switching Diode 75V 150mA SOT-23 currently costs 4 EGP in Egypt.
Where can I buy BAS16 SMD Switching Diode 75V 150mA SOT-23 in Egypt?
BAS16 SMD Switching Diode 75V 150mA SOT-23 is available from Makers Electronics. Compare the offers above to find the best price.
Can it clamp a small relay coil?
It can serve as a freewheeling diode for low-current inductive loads such as small relay coils, as long as the 150 mA average current rating is not exceeded. Place it reverse-biased across the coil.
Is it suitable for mains power rectification?
No. It is a small-signal switching diode rated for 150 mA. For mains or power rectification, use a rectifier diode or bridge rated for the required voltage and current.
