ADS1115 16-Bit I2C ADC Module, 4-Channel with PGA
Prices updated: 13 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 MicroohmCheapest | ADS1115 16-Bit ADC- 4 Channel with Programmable Gain Amplifier | 250 EGP350 | View in store |
 Ekostra | ADS1115 16-Bit I2C ADC Module 4-Channel | 275 EGP | View in store |
 Makers Electronics | ADS1115 16-Bit ADC 4-Channel with Programmable Gain Amplifier | 275 EGP | View in store |
Price history
Lowest daily price, last 90 days
Lowest price recorded: 250 EGP
About this product
The ADS1115 is a 16-bit analog-to-digital converter with an I2C interface, four single-ended inputs (or two differential) and a programmable-gain amplifier. It is used for precise voltage measurement, sensor interfacing and battery monitoring with microcontrollers such as Arduino, ESP32 and Raspberry Pi.
Specifications
- Resolution
- 16-bit
- Interface
- I2C
- Channels
- 4 single-ended or 2 differential
- Supply voltage
- 2.0 V to 5.5 V
- Data rate
- 8 to 860 SPS
- Input ranges
- ±0.256 V to ±6.144 V (programmable)
- I2C addresses
- 0x48 to 0x4B
- Continuous mode current
- 150 µA
Frequently asked questions
What is the price of ADS1115 16-Bit I2C ADC Module, 4-Channel with PGA in Egypt?
ADS1115 16-Bit I2C ADC Module, 4-Channel with PGA currently costs between 250 and 275 EGP across 3 offers in Egypt.
Where can I buy ADS1115 16-Bit I2C ADC Module, 4-Channel with PGA in Egypt?
ADS1115 16-Bit I2C ADC Module, 4-Channel with PGA is available from Microohm, Ekostra, and Makers Electronics. Compare the offers above to find the best price.
How do I set the I2C address of the ADS1115?
Connect the ADDR pin to GND for 0x48, VDD for 0x49, SDA for 0x4A or SCL for 0x4B. Use the same address in your code when you initialize the device.
Can I use the ADS1115 with a 3.3 V board like ESP32?
Yes. Power the module from 3.3 V and keep every input between 0 V and VDD, because channel inputs must not exceed the supply rail. Check whether the module already has pull-up resistors on SDA and SCL before adding external ones.
