75454N Dual High-Speed High-Current Peripheral Driver DIP-8
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | 75454N Dual Very-High Speed, High-Current Dual Peripheral Drivers IC DIP 8-Pins | 10 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 10 EGP
About this product
The 75454N is a dual very-high-speed, high-current peripheral driver in an 8-pin DIP package. Its open-collector outputs are rated up to 30 V and 300 mA, and its inputs are TTL-compatible. It is used as a buffer to drive lamps, LEDs and other loads from logic circuits.
Specifications
- Channels
- 2
- Output voltage
- Up to 30 V
- Output current
- Up to 300 mA
- Output type
- Open collector
- Input logic
- TTL-compatible
- Package
- DIP-8
Frequently asked questions
What is the price of 75454N Dual High-Speed High-Current Peripheral Driver DIP-8 in Egypt?
75454N Dual High-Speed High-Current Peripheral Driver DIP-8 currently costs 10 EGP in Egypt.
Where can I buy 75454N Dual High-Speed High-Current Peripheral Driver DIP-8 in Egypt?
75454N Dual High-Speed High-Current Peripheral Driver DIP-8 is available from Makers Electronics. Compare the offers above to find the best price.
Do I need a pull-up resistor with the 75454N?
Not for driving a load to ground. The outputs are open-collector and sink current to ground, so connect the load between its supply and the output pin. Add a pull-up resistor only where the output must actively read as high.
Can the 75454N drive LEDs or lamps directly?
Yes, within the 300 mA per-output limit. For LEDs, include a series current-limiting resistor. Keep the total power dissipation of the package in mind when several channels are loaded at once.
