74LS07 Hex Buffer Open-Collector IC 5 V DIP-14
Prices updated: 12 Oct 2026
Compare prices
| Store | product | Price | View in store |
|---|---|---|---|
 Makers Electronics | 74LS07 Open Collector Buffer 5V 40mA DIP-14 | 18 EGP | View in store |
Price history
Lowest daily price, last 90 days
Not enough price history yet.
Lowest price recorded: 18 EGP
About this product
The 74LS07 is a TTL hex buffer with six open-collector outputs, designed for 5 V logic. Open-collector outputs allow wired logic and driving loads at a higher voltage through external pull-up resistors. It comes in a 14-pin DIP package and can sink up to 40 mA per output.
Specifications
- Logic family
- 74LS (TTL)
- Supply voltage
- 5 V
- Buffers per package
- 6 (hex)
- Output type
- Open collector
- Output current
- 40 mA
- Package
- DIP-14
Frequently asked questions
What is the price of 74LS07 Hex Buffer Open-Collector IC 5 V DIP-14 in Egypt?
74LS07 Hex Buffer Open-Collector IC 5 V DIP-14 currently costs 18 EGP in Egypt.
Where can I buy 74LS07 Hex Buffer Open-Collector IC 5 V DIP-14 in Egypt?
74LS07 Hex Buffer Open-Collector IC 5 V DIP-14 is available from Makers Electronics. Compare the offers above to find the best price.
Why does the 74LS07 need a pull-up resistor?
An open-collector output can only pull the line low. A pull-up resistor to the supply, or to a higher voltage, is required for the output to go high. Choose its value so the sink current stays within 40 mA per output.
Can it drive an LED or a relay?
It can drive LEDs through a pull-up resistor from a supply rail, as long as the sink current stays within 40 mA. Relays and motors need more current, so drive them through a transistor stage instead.
